• Long tiller design for ergonomics and safety; • Emergency reversing device in the handle provides higher safety for thewhole operation; • Braking applied with handle upright and horizontal position, increasing the safety of the truck; • Multi-function display with hour meter; • Built-in pressure relief valve protects the trucks from overloads, and increases the reliability; • Emergency power disconnect switch; • Turtle-shaped low speed switch; • Auto deceleration function makes operation more safely.
Model | CDD15/16 | |||
Maximum load capacity | 1500/1600kg | |||
load center | 600mm | |||
Travel speed without load/with load | 4.5/3.5km/h | |||
Lifting speed without load/with load | 140/80mm/s | |||
Lowered speed without load/with load | 100/80mm/s | |||
Ascend slope ability without load/with load | 7/4% | |||
Overall length/width of frame | 1860/850 | |||
Wheelbase | 1250mm | |||
Fork size(length *width*thickness) | 1150*165*55mm | |||
Fork outside width | 550/685mm | |||
Min frounf height | 28mm | |||
Fork lowered height | 90mm | |||
Minimum turning radius | 1530mm | |||
Minimum intersecting aisie | 2400mm | |||
Front wheel | 80*70mm | |||
Drive wheel | 210*75mm | |||
Caster wheel | 115*55mm | |||
Drive motor Rated output/DC motor | 0.75kw | |||
Hoist motor Rated output/DC motor | 2.2kw | |||
Battery Voltag/Capacity | 24/85V/Ah | |||
Battery Weight | 26*2kg | |||
Mast | Max.Lifting height | Mast overall height | Mast overall height | Service weight |
Single mast | 1600 mm | 2080 mm | 2080 mm | 460 kg |
2-stage mast | 2000 mm | 1580 mm | 2550 mm | 520 kg |
2500 mm | 1830 mm | 3050 mm | 530 kg | |
3000 mm | 2080/1980 mm | 3550/3450 mm | 540 kg | |
3500 mm | 2330 mm | 4050 mm | 620 kg |
