Forklifts are widely used in ports, stations, airports, freight yards, factory workshops, warehouses, distribution centers, and distribution centers. They are important equipment for loading, unloading, and handling palletized goods in ship cabins, carriages, and containers. 1. Our engine is with low emission, optimized distribution device and advanced fuel system make it has good low temperature starting performance, high reliability, compact structure, smooth power transmission characteristics. 2. The performance of forklift imported high quality electronic instrument is reliable. It is convenient for the operator to observe various data from electronic instrument during operation. 3. Wide visible range during operation ensures the safety and accuracy of work. 4. Effectively prevent sliding when the body start again after stopping at the slopes and ensure safe operation 5. Specially heightened air inlet position prevent the air filter away from dust and draw clean air. The special design improves work efficiency of the engine and prolong engine life. 6. specially increased water tank. Water cooling area and water tank capacity is 1.25 times that of similar products,enables the forklift wouldn't emerge the overheating phenomenon.
Model | 7T |
RATED LOAD LIFTING CAPACITY | 7000KG |
TOTAL WEIGHT | 8750kg |
FORK LENGTH | 150*1500MM |
ENGINE MODEL | QUANCHAI 4C6 turbo |
RATED POWER | 76kw |
RATED SPEED | 2400r/min |
DIMENSION | 4750(WITHOUT FORK)*2120*2820MM |
TYRE TYPE | 16/70-20 |
MIN.TURNING RADIUS | 2650mm |
STANDARD LIFTING HEIGHT | 4000MM |
GANTRY ANGLE | FRONT 6°/REAR 12° |
MINIMUM GROUND CLEARANCE | 230MM |
WHEEL BASE | 2360MM |
WHEEL TRACK | 1735mm |
LOAD CENTRE DISTANCE | 500mm |
