The “MINGYU” brand is recognised internationally as the “Excellent Trade Mark. MINGYU forklift has been Top 7 in the world since 2023 and has been Top 1 in China for 27 years continuously since 1996. The competitive edge of MINGYU brands of product lies with its competitive product line, advanced production, R&D capability, reliability and durability. 1、Vibration reduced to relieve driver’s fatigue greatly. 2、Equipped with optimised designed parts around the engine so that noise are reduced greatly. 3、With the optimised cooling system and improved cooling performance, it increases the reliability and durability of the transmission, engine and many key parts. 4、Strengthen and optimised core structure parts, strength improved greatly; with intelligent gear shifting technology to avoid 2nd-gear start, improved transmission life.
Model | B50 | |
Power Type | accumulator | |
rated load lifting capacity | 5000kg | |
Load centre distance | 500mm | |
driving style | Sit down | |
length | with fork | 4510mm |
without fork | 3275mm | |
wideth | 1430mm | |
height | Do not raise the mast height | 2280mm |
Overhead guard height | 2175mm | |
Max height at working | 4210mm | |
wheel base | 2215mm | |
front overhang | 517mm | |
rear overhang | 560mm | |
front wheel track | 1150mm | |
rear wheel track | 1020mm | |
minimum ground clearance | 180mm | |
Standard lifting height | 3000mm | |
free lifting height | 45mm | |
Fork adjustment range | 300-1380mm | |
minimum turning radius | 2980mm | |
Minimum right-angle channel width(1100*1100 pallets) | 4797mm | |
Gantry angle (front/rear) | 6/12° | |
Maximum lifting speed without load | 315mm/s | |
Maximum lifting speed with full load | 280mm/s | |
Maximum operating speed without load | 15Km/h | |
Maximum operating speed with full load | 13Km/h | |
Max gradeability with full loading | 15% | |
Weight unladen | 5740kg | |
Number of wheels = driving wheels/steering wheels | 2/2 | |
Tyre type (front/rear) | Pneumatic tyre/solid tyre | |
tyre size(front) | 250-15 | |
tyre size(rear) | 6.50-10 | |
Brake/driving brake | Foot Brake | |
parking brake | Hand Brake | |
Battery voltage/capacity | 153.6V/175AH | |
drive motor power | 21.6KW | |
Oil pump motor power | 22.6KW |
