MYZG CPD25-B electric Forklift

load capacity
2.5ton

power
Lithium Battery

Weight unladen
4500kg

Mini. Order
1 unit

Feature

CPD25-B series lithium battery forklifts are high quality products developed by MINGYU on the basis of the advantages of "lithium battery special structure" and "permanent magnet synchronous technology". It has two models, one is standard model and the other is heavy-duty model. Following the family design of electric forklifts, they are provided with some key parts compatible with internal combustion forklifts, and optimized mainly on the overall performance, ergonomics, reliability, maintenance, outdoor operation ability and load capacity in a bid to meet customers’ use scenarios of internal combustion forklifts. The heavy-duty model is capable of meeting the application demand of users in heavy-duty working conditions.

Discription

ModelCPD25
Power Typeaccumulator
rated load lifting capacity2500kg
Load centre distance500mm
load centre distanceSit down
lengthwith fork3290mm
without fork2210mm
wideth1100mm
heightDo not raise the mast height2010mm
Overhead guard height2000mm
Max height at working4110mm
Distance from seat surface to top guard frame980mm
wheel base1520mm
front overhang370mm
rear overhang380mm
front wheel track904mm
rear wheel track958mm
minimum ground clearance110mm
Standard lifting height3000mm
free lifting height0mm

Fork adjustment range260-1100mm
minimum turning radius2100mm
Minimum right-angle channel width(1100*1100 pallets)3670mm
Gantry angle (front/rear)5/10°
Maximum lifting speed without load325mm/s
Maximum lifting speed with full load250mm/s
Maximum operating speed without load15Km/h
Maximum operating speed with full load14Km/h
Max gradeability with full loading15%
Weight unladen2980Kg
Number of wheels = driving wheels/steering wheels2/2
Tyre type (front/rear)Pneumatic tyre/pneumatic tyre
tyre size(front)6.50-10
tyre size(rear)5.00-8
Brake/driving brakeFoot Brake
parking brakeHand Brake
Battery voltage/capacity80V/105Ah
drive motor power13Kw
Oil pump motor power13Kw
fork length1070mm
