MYZG CPD18-B electric Forklift
load capacity
1.8ton
power
Li-ion
operating weighht
2810Kg
Mini. Order
1 unit
Feature
The Mingyu B18 Lithium Battery Forklift is designed for optimal performance in tight and confined spaces. With a short wheelbase and a small turning radius, this forklift can easily navigate through narrow aisles and corners, making it an ideal choice for warehouses, factories, and other environments where space is limited.
Discription
| Model | A18 | |
| Power Type | Li-ion | |
| rated load lifting capacity | 1800KG | |
| Load centre distance | 500mm | |
| driving style | Driving style | |
| length | with fork | 3100mm |
| without fork | 2020mm | |
| width | 1100mm | |
| height | Do not raise the mast height | 2060mm |
| Overhead guard height | 2010mm | |
| Max height at working | 4050mm | |
| wheel base | 1315mm | |
| front overhang | 350mm | |
| rear overhang | 380mm | |
| front wheel track | 925mm | |
| rear wheel track | 920mm | |
| minimum ground clearance | 120mm | |
| Standard lifting height | 3000mm | |
| free lifting height | 80mm | |
| Fork adjustment range | 260-1100mm | |
| minimum turning radius | 1800mm | |
| Minimum right-angle channel width(1100*1100 pallets) | 3450mm | |
| Gantry angle (front/rear) | 6/12° | |
| Maximum lifting speed without load | 430mm/s | |
| Maximum lifting speed with full load | 360mm/s | |
| Maximum operating speed without load | 15Km/h | |
| Maximum operating speed with full load | 14Km/h | |
| Maxi climbing slope under full load | 15% | |
| overall weight | 2810Kg | |
| Number of wheels = driving wheels/steering wheels | 2/2 | |
| Tyre type (front/rear) | pneumatic | |
| tyre size(front) | 6.50-10 | |
| tyre size(rear) | 5.00-8 | |
| Brake/driving brake | foot brake | |
| parking brake | hand brake | |
| Battery voltage/capacity | 80V/105AH | |
| Charger | 80V/35A | |
| Drive motor power | 13Kw | |
| Oil pump motor power | 13Kw | |
